Single Core Cable

SINGLE CORE CABLE

Technical Data :
Operating Temp : -200C to max.+800C
Nominal Voltage : 1100 V
Test Voltage : 3000 V
Insulation resistance : Min. 20 M ohm x km
Min. Bending Radius : 7 X Cable Diameter
Flame Propagation : Flame Retardant Test As Per IEC 60332-1

TECHNICAL INFORMATION

Cross Sectional Area Copper Construction Inner Dia. Outer Dia Appx. Max. Conductor
Resistance at 20˚C
Sq. mm. Nos. / Dia. mm mm mm Ω/km
10 322 / 0.20 6.30 9.90 1.910
16 511 / 0.20 8.00 10.70 1.210
25 798 / 0.20 9.50 12.10 0.780
35 1121 / 0.20 11.00 14.20 0.554
50 1596 / 0.20 12.30 16.30 0.386
70 2220 / 0.20 14.40 18.70 0.272
95 1349 / 0.30 16.60 20.80 0.206
120 608 / 0.50 18.20 23.00 0.161
150 760 / 0.50 21.10 27.60 0.129
185 943 / 0.50 23.80 30.80 0.106
240 1225 / 0.50 26.80 34.00 0.0801
Special heat resistant insulation
Higher current carrying capacity.
Fine copper wires
Highly thermal stable insulation
Excellent resistant to moisture, abrasion, grace, oil
Long Life
Excellent mechanical & electrical properties
Conductor :
EC copper class 5 and class 6 generally conforms to IEC 60228, DIN VDE 0281
Insulation :
XLPE
Sheath :
Flexible Nitrile rubber (NBR) Orange, Black, Red, Blue Jacket
*Any other Color on specific request can also be supplied
1 :
For applications where extreme flexibility is required - high current capacity. Power - Switchboards, flexible droppers from bus bars, transformers, load banks or other equipment requiring fixed or flexible wiring. Pumping - Suitable for permanent submersion
2 :
Fixed installation in conduits and under plaster, for appliance wiring & distribution stations. Fixed Wiring in Conduits & Building wire Application.
